When You Need More Than a Basic Radio

Only Icom quality can offer this simple to use but versatile rich featured radio. In this compact light weight body, many attractive features such as multiple signaling, large capacity Lithium-Ion battery and wide frequency coverage are built-in. This rugged handheld easily exceeds your expectations with reliable performance and communication quality.

Compact lightweight body
The rounded compact* design fits comfortably in your palm and is light-weight** for carrying around all day. The large size programmable buttons have ample button-pitch to allow blind touch operation.
* 53(W)×120(H)×36.9(D) mm; 2³/₃₂× 4²³/₃₂×1⁷/₁₆ in
** 296g; 10.4oz including BP-232N

IP54 dust-protection and splash resistance
The IC-F3021 series meets IP54 requirements for dust-protection and splash resistance. The aluminum die-cast chassis is the basis for this rugged construction, allowing long-life usage in various environments.

128 memory channels
and button control memory channel
The IC-F3021 series has 128 memory channels with 8 zones. Memory channel selection can be made easily with the up/down buttons laid out below the PTT button.

Most popular signalings built-in
Use the built-in 2-Tone, 5-Tone, CTCSS and DTCS capabilities as standard to set up your own talk groups and quiet stand-by when others are talking.

Multiple 2-Tone, Multiple 5-Tone
Up to ten 2-Tone and eight 5-Tone codes can be decoded on a channel. When a matched tone is received, the following items are programmable for each code.

• Beep sound
• Answer back
• Scan
• Bell icon
• Radio stun/kill

Lithium-Ion battery standard
Supplied 2000mAh Li-Ion battery pack, BP- 232N, provides 15.5 hours* of operating time. Li-Ion batteries have virtually no memory issues and allows you flexible charging.
* Typical operation; Tx:Rx:Standby=5:5:90, power save on

8 programmable buttons
The [P0]–[P3], [▲], [▼], [Monitor] and [Red] buttons are programmable to meet specific needs. The [Red] button on the top panel can be assigned as an emergency trigger.

Alphanumeric display
The 8-character alphanumeric display shows channel, zone, tone code and scanning channel names on the display. A separate row of operational icons indicate battery, signal strength, RX/TX and other radio conditions.

Wide frequency coverage
The IC-F3021 series covers a wide frequency range with one version (136–174, 400–470, 450–512 (520) MHz). Wide and narrow channel spacing (25, 12.5kHz) is programmable per channel.

Optional board
The IC-F3021 series has a 40-pin expansion socket for adding an optional board. A voice scrambler provides secure conversation and the DTMF decoder features has ANI capability, depending on the installed board.

Optional VOX headset
With one of Icom’s optional headsets and PTT/VOX unit, the IC-F3021 series offers hands-free operation.

Other features
